توضیحات
Camera
Image Sensor
2 MP CMOS
Max. Resolution
1920 (H) × 1080 (V)
Scanning System
Progressive
Electronic Shutter Speed
PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s
Min. Illumination
0.001 lux@F1.6 (Color, 30 IRE)
0 lux (Illuminator on)
S/N Ratio
>65 dB
Illumination Distance
40 m (131.23 ft)
Illuminator On/Off Control
Auto
Illuminator Number
4 (Warm light)
Angle Adjustment
Pan: 0°–355°
Tilt: 0°–90°
*DO NOT adjust the angle of the main body or enclosure manually
Lens
Lens Type
Fixed-focal
Auto Focus
No
Lens Mount
M12
Focal Length
2.8 mm;3.6 mm
Max. Aperture
F1.6
Field of View
2.8 mm: H: 106°; V: 56°; D: 127°
3.6 mm: H: 86°; V: 46°; D: 101°
Iris Control
Fixed
Close Focus Distance
2.8 mm: 0.8 m (2.62 ft)
3.6 mm: 1.1 m (3.61 ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8 mm
43.9 m
(144.03 ft)
17.5 m
(57.41 ft)
8.8 m
(28.87 ft)
4.4 m
(14.44 ft)
3.6 mm
53.7 m
(176.18 ft)
21.5 m
(70.54 ft)
10.7 m
(35.10 ft)
5.4 m
(17.72 ft)
Video
Video Frame Rate
CVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960H;
NTSC: 960H
Resolution
1080p (1920 × 1080); 960H (960 × 576/960 × 480)
Day/Night
Color
BLC
BLC; WDR; HLC
WDR
130 dB
White Balance
Auto;Area white balance
Gain Control
Auto
Noise Reduction
3D NR
Illumination Mode
Smart Light
Mirror
Yes
Privacy Masking
Off/On (8 areas, rectangle)
Certification
Certifications
CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035
Port
Video Output
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Input
One channel built-in Mic
Power
Power Supply
12 VDC ± 30% (It is recommended to use a power adapter to supply the power for one camera)
Power Consumption
Max 6.2 W (12 VDC, LED on)
Environment
Operating Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity
<95% (RH), non-condensing
Storage Temperature
–40 °C to +60 °C (–40 °F to +140 °F)
Storage Humidity
<95% (RH), non-condensing
Protection
IP66
Anti-corrosion Level
Basic Protection
Structure
Casing Material
Plastic
Product Dimensions
92.9 mm × 91.3 mm × 130 mm (3.66" × 3.59" × 5.12")
Net Weight
0.38 kg (0.84 lb)
Gross Weight
0.62 kg (1.37 lb)
Installation
Wall mount; ceiling mount; vertical pole mount
